| TUBE & PIPE |
| |
| STAINLESS TUBES |
| |
|
|
| |
| HEAT EXCHANGER TUBES |
| |
| Steel Grade |
Stainless Steel |
304/304L 316/316L 316T1 310S 317L 321/321H 347/347H 410S
S31803 S32750 |
| Alloy & Carbon Steel |
A213-T11 ~T91 A210 A179 A192 A178 |
| Special Steel |
Inconel600 Inconel625 Incoloy800 Incoloy825 Monel & Others |
| Specification |
ASTM ASME AISI DIN JIS |
Product
Range |
Out Diameter |
2.0mm ∼ 88.9mm |
| Wall Thickness |
0.3mm ∼ 8.0mm |
| Maximum Length |
32 meters |
Main Product
Range |
Out Diameter |
31.75mm 25.40mm 19.05mm 15.88mm 12.70mm 9.53mm 6.35mm |
| Wall Thickness |
2.77mm .41mm 2.11mm 1.65mm 1.24mm 0.89mm |
| Purpose |
Heat Exchanger, Boiler, Atomic Power Plant, Desalination Plant, Condenser, Super Heater |
|
| |
| STAINLESS PRECISION TUBES |
| |
| Steel Grade |
Stainless Steel |
304/304L 316/316L 316T1 310S 317L 321/321H 347/347H 410S
S31803 S32750 |
| Special Steel |
Inconel600 Inconel625 Incoloy800 Incoloy825 Monel & Others |
| Specification |
ASTM ASME AISI DIN JIS |
| Specification |
Seamless / Semi-Seamless Tube |
Product
Range |
Inner Diameter |
1.0mm ∼ 88.0mm |
| Wall Thickness |
0.05mm ∼ 8.0mm |
| Purpose |
Precision Cylinder |
Gas Cylinder Air Cylinder Oil Cylinder |
| Precision Parts |
Fine Electric & Electronic Parts, Medical Appliance,
Bending Machine, Compressor, Fitting, Tubing,
Automobile Parts, Measurement Appliance, Precise Shaft & Roller |
| Special Parts |
Semi-conductor, Transportation Line, Ship Building, Aero Space Industry |
|
| |
| U BENDING TUBES |
| |
|
| |
| FINNED TUBES |
| |
|
| |
|
